Actuator Technology
Something not many people know: EBRO produces its own actuators - and has been doing so for
30 years. For EBRO customers this means that butterfl y and gate valves can always be equipped
with the most suitable actuator. No compromises, just the best possible match of components - this
is what the EBRO actuator series stands for. Pneumatic actuators, single or double acting, have
been proven for decades. However, industrial process air is expensive. Energy effi ciency is there-
fore the topic of the day. As a manufacturer of valves and actuators, EBRO can specifi cally match
single product components according to customer requirements and within the scope of operating
conditions, thus substantially reducing regular operating costs.
EB-SYS & EB-SYD E65 - E210
The scotch-yoke principle in the EB actuators exactly A compact series of electric actuators for open/close and control
matches the valve torque characteristics, thus reducing size functions.
and air consumption.
Torque range: 27 - 9768 Nm (based on supply Actuation time 6 sec. - 25 sec.
pressure of 6 bar) from 0° - to 90°:
End positions: exactly adjustable between -8°/3° Rated torque: 40 Nm - 3500 Nm
Limit switch- and Cont- VDI / VDE 3845 Rated current: 0,15 A - 8,8 A
rol valve-fi tting:
Control pressure: min. 2,5 bar, max. 8 bar Starting current: 0,18 A - 12,5 A
Control air: Filtered compressed air dry or Power consumption: 0,04 kW - 0,54 kW
lubricated.
-20°C to +80°C (standard)
Temperature range: -40°C to +80°C (low temperture) Rated voltage: 24 V - 400 V
-15°C to +120°C (high temperture)
high quality marine grade Alumi-
Cylinder liner: nium alloy, hard anodized. Frequency: 50 Hz - 60 Hz
Other coatings upon request
Duty cycle: 30%
IP 67
Protection class:
IP 68 optional
